Data Input :
SDI Video Input: SD/HD/3G-SDI (BNC 75O) x1
HDMI Video Input: SD/HD/3G (HDMI Type A) x1
Reference Input: B.B , TRI (BNC 75O) x1
Audio Input: D-SUB 9PIN (Female) x1
Video Formats :
- 720x480i@59.94/60
- 720x576i@50
- 1280x720p@50/59.94/60
- 1920x1080i@50/59.94/60
- 1920x1080p@23.98/24/25/29.97/30
- 1920x1080p@50/59.94/60
Data Output :
- SDI Video Output: SD/HD/3G-SDI (BNC 75O) x1
- HDMI Video Output: SD/HD/3G (HDMI Type A) x1
- Audio Output: D-SUB 9PIN (Female) x1
Video Formats :
- 720x480i@59.94 (DIP SW : 1111)
- 720x576i@50 (DIP SW : 0111)
- 1280x720p@50 (DIP SW : 1011)
- 1280x720p@59.94 (DIP SW : 0011)
- 1280x720p@60 (DIP SW : 1101)
- 1920x1080i@50 (DIP SW : 0101)
- 1920x1080i@59.94 (DIP SW : 1001)
- 1920x1080i@60 (DIP SW : 0001)
- 1920x1080p@23.98 (DIP SW : 1110)
- 1920x1080p@24 (DIP SW : 0110)
- 1920x1080p@25 (DIP SW : 1010)
- 1920x1080p@29.97 (DIP SW : 0010)
- 1920x1080p@30 (DIP SW : 1100)
- 1920x1080p@50 (DIP SW : 0100)
- 1920x1080p@59.94 (DIP SW : 1000)
- 1920x1080p@60 (DIP SW : 0000
